• RC8X Firmwares

Latest Firmware

Note: When using a Windows system computer to upgrade, you can directly connect the RC8X to the computer with a Type-C cable to upgrade, while if you use a Mac system computer to upgrade, you need to take out the memory card from the RC8X and use a card reader to upgrade.





Attention:

If you can not download the files when clicking the mac file above, please click the website below to download the files you need.

http://www.radiolink.com.cn/firmware/transmitter/RC8X/





Attention:

After upgrading the complete upgrade firmware package, all the settings including the customized contents, such as voice broadcast content, icons, etc., will be restored to the factory default settings. If you have set several models' parameters or customized content before the upgrade, you can copy the setting contents from the RC8X disk to the computer to save them, and then copy the data back to the RC8X storage disk after upgrading the latest firmware.

For the model parameters, you can copy the contents of the [model] folder in the RC8X_INT disk to the computer and save them, and then copy the data back to the RC8X storage disk after upgrading the latest firmware.

② For the customized contents, you can copy them in RC8X_EXT, for example, the customized voice broadcast package content is saved in the [sounds] folder.



When upgrading, how to choose the right packs?

1. If your RC8X has set lots of customized content, such as voice broadcast content, icons, etc., and you do not want to change this customized content after upgrading, then please choose the fix packs to upgrade. While, if you want to restore all RC8X settings to factory data through a firmware upgrade, then choose the complete upgrade firmware package.

2. If you choose the fix packs to upgrade, you can only upgrade level by level. If you choose the complete upgrade firmware package, you can upgrade across levels. For example, if you choose the fix packs to upgrade the firmware from the current V1.0.8 version to the latest version V1.1.0, you have to upgrade the firmware to V1.0.9 first, and then upgrade from V1.0.9 to V1.1.0. While, if you choose the complete upgrade firmware package, you can directly upgrade from V1.0.8 to V1.1.0.





Attention:

After upgrading the latest firmware V1.1.2, the parameters below you have set will be restored to the factory default settings.

  • All the settings in the “Battery” menu
  • All the settings in the “External input output” menu



Firmware V1.1.2 Upgrade Instructions

1. Repair the model does not report errors when it fails to select but opens the Model_1 automatically.

2. Fix the problem that the parameters will fail to save when selecting a new model if the RC8X has been powered off abnormally.

3. Model sorting is sorted according to the model creation time.

4. When creating a new model, automatically enter the rename interface to avoid stuttering when the number of models is created too much.

5. Fix the problem that the model data being deleted when using special characters to rename the model.

6. In the “Battery” menu, add no operation alarm prompt function and no operation automatic power-off function.

7. Repair the model renamed only in English to display problems

8. In the case of non -compulsory shutdown, the device shutdown will prompt “Please power off the receiver first to avoid accidents! Do you want a forced shutdown?”.

9. In the “Trim/Dial select” menu, add the trimers back to the center automatically function.

10. In the “External input output” menu, add the function that the PPM value can be set according to your need.

11. Repair the problem of the “Fail-safe” function abnormal

12. In the “Fail-safe” menu, add a quick setup function for every channel.

13. Repair the 8-channel display abnormal problem in the “end point” menu.
