Q: Can RadioLink ATA ELRS 1W long-range module be installed with the firmware downloaded from the ExpressLRS website?
Q: Can RadioLink ATA ELRS 1W long-range module be installed with the firmware downloaded from the ExpressLRS website?
A: No. It only supports the firmware from RadioLink official website.
Firmware download link: https://www.radiolink.com/elrs1w_firmwares
Q: How to set the channel to detect “ARMED”or “DISARMED”for ExpressLRS?
Q: How to set the channel to detect “ARMED”or “DISARMED”for ExpressLRS?
A: To ensure safety and high performance, AUX1 (channel 5) is the channel ExpressLRS uses to detect "ARMED" and “DISARMED”. A low value (1000) of the arm switch is disarmed, and a high value (2000) is armed.
For more details, please refer to the below link:
https://www.expresslrs.org/software/obsolete-defines/#obsolete-defines
Q：What receivers can work with the ATA ELRS 1W module?
Q：What receivers can work with the ATA ELRS 1W module?
A: ATA ELRS 1W module only supports ELRS receiver.
Q: Can ATA ELRS 1W module can work with RadioLink RC8X/AT9S Pro/AT10Il transmitter?
Q: Can ATA ELRS 1W module can work with RadioLink RC8X/AT9S Pro/AT10Il transmitter?
A: No. ATA ELRS 1W module can work with all the open TX and part of the closed-sourcetransmitters include T16D, T12D, T16Z,T16SZ,T18SZ, ET16, etc.
Q: What is the control range of ATA ELRS 1W long-range module?
Q: What is the control range of ATA ELRS 1W long-range module?
A: The control range depends on the power of the module. The power of the ATA ELRS 1Wlong-range module can be set to 25mW/50mW/100mW/250mW/500mW/1W. The higher thepower, the longer the control range. When the power of the ATA ELRS 1W long-range module is1W, the control range exceeds 5 kilometers.
